Operation 35
Single Plot Exercise
1. Turn on the HS15
plus
. Load plotting paper, install the pen and pen
holder, and set the tool force to .5.
2. Using the slew keys, position the carriage spindle approximately 1"
from the front edge of the plotting paper. Also, be sure that there are
several inches of paper extending past the carriage spindle and to the
left of the plotter.
3. Send a plot file to the
HS15
plus
plotter.
4. Press the
RUN SINGLE
key to plot the test exercise.
RUN CONT KEY
Use
RUN CONT
to access the continuous plotting mode and maximize
the plotter's productivity.
To plot in continuous mode
1. Select either swivel or tangential knife mode by pressing the
SWIVEL KNIFE
key. When swivel knife mode is selected, the light
above the
SWIVEL KNIFE
key is on.
2. Press
RUN CONT
. The light over the
RUN CONT
key comes on and
the HS15
plus
plots one job after the other without waiting for user
prompting between the jobs.
When one job finishes plotting, the next job in the queue begins
immediately. When all jobs in the queue are plotted, the HS15
plus
remains on-line until the operator presses either Run key or the
RESET
key to return to off-line status.
RUN
CONT
