Gerber HS15 Plus - HS15 Plotter Parts List

Appendix 63
HS15
plus
Plotter Parts List
Number Part Description
1 Base & Side Plate Assy.
2 Sensor Disk Cam Assy.
3 Rear Way Grooved
4 Drum Assy.
5 Front Way
6 Bearing Ball .375 x .875 x .281
8 Left Bail Arm Assy.
9 Right Bail Arm Assy.
10 Paper Bail & Wheel Assy.
11 Shoulder Screw (Lt. Bail Arm)
12 Shoulder Screw (Rt. Bail Arm)
13 Spacer 8-32 x .312 x 01 x 1.25
14 Spacer 8-32 x .312 x 01 x .531
17 Theta Gear & Sensor Disk
18 X Axis Gear
22 Z & Theta Motor & Plate Assy.
23 Theta Servo Motor
24 Y Axis Motor & Plate Assy.
25 X Axis Motor & Plate Assy.
