Error Conditions 45
ERROR CODES
The error code numbers and suggested operator responses are listed
below as well as on the
HS15
plus
Reference Card
.
Error
Number Error Description Operator Response
1 Program checksum failure Try power up again.
2 RAM memory failure Try power up again.
3 Plotter type error Call Gerber Field Service.
4 Power relay closed Call Gerber Field Service.
5 Power relay open Call Gerber Field Service.
6 Peripheral control chip
error
Call Gerber Field Service.
7 Heartbeat error Call Gerber Field Service.
8 Motor encoder failure Call Gerber Field Service.
9 X motor encoder failure Call Gerber Field Service.
10 Y motor encoder failure Call Gerber Field Service.
11 Z motor encoder failure Call Gerber Field Service.
12 Theta motor encoder
failure
Call Gerber Field Service.
13 Power relay off Try power up again or call
Gerber Field Service.
14 X axis error Call Gerber Field Service.
Call Gerber Field Service Department at 800-828-5406 (in the USA), or fax at 203-645-2448.
