46 HS15
plus
Error
Number
Error Description Operator Response
15 Y axis error Call Gerber Field Service.
16 Z axis error Call Gerber Field Service.
17 Theta axis error Call Gerber Field Service.
18 RS-232 test failure Call Gerber Field Service.
19 Illegal plot data command Check plot data; resubmit
plot.
20 Plotter has overheated Allow plotter to cool down
or move it to a cooler area.
Call Gerber Field Service.
21 Illegal interrupt error Try power up again. Call
Gerber Field Service.
22 Unknown interrupt error Try power up again. Call
Gerber Field Service.
23 Theta home error Try power up again.
24 Z home error Try power up again.
25 Y home error Try power up again.
26 Data overflow (only for
HPGL data)
Check communication
parameters (baud rate, etc.)
27,28,29 Problems with baud rate,
data bits, parity bits, stop
bits
Call Gerber Field Service.
