40 HS15
plus
Square/Circle Test Plot
−
Press the
SLOW
key. Used to check X, Y,
Z, and theta axes in cut mode and to verify operation after
adjustments are made.
X08 Cut Test
- Press the down arrow key to access. Use to test cut
quality.
Note: If the plotter consistently fails a special diagnostic, contact
Gerber Field Service Department at 800-828-5406, or fax at 203-645-
2448.
WAGON WHEEL TEST PLOT
To plot the Wagon Wheel Test Plot
1.
Load plotting paper and install the pen holder.
2.
Press left arrow key to access diagnostic.
3.
Press
RUN SINGLE
to plot once or
RUN CONT
to plot continuously.
4.
Compare the test plot to the illustration below. If they do not look
the same, call Gerber Field Service.
