20 HS15
plus
PEN REPLACEMENT
Spare pens in blue and red are included in the tool kit. Additional pens
are available through your Gerber distributor.
To replace a pen
1. Insert a flat-tip screwdriver into the notch at the base of the tool cap
(see below). Pry out the cap.
2. Use an Allen wrench to loosen the hex screw located near the tip of
the pen. (See the photograph on the next page.) Remove the pen
through the top of the holder.
3. Insert a new pen, tip first, into the top of the holder.
4. The pen height gage included with the tool kit is a washer 1/8 inch
thick. Place the pen height gage on a smooth, hard surface like a
table top. Position the lower end of the pen holder on the gage. (See
the photograph on the next page.)
