36 HS15
plus
Controlled Stop
Use
RUN CONT
(or
RUN SINGLE
) to stop plotting and check the
current job.
To stop a continuous mode plot
1. Press either Run key. The HS15
plus
stops the plot at the next logical
break in the program.
Note: The slew keys may be pressed to maneuver the carriage or
material. However, when the Run key is pressed again to exit the
pause mode, the plotter will return the carriage and material to the
point where the job was paused.
2. Press either Run key to resume plotting at the exact same point.
Continuous Plot Exercise
1. Turn on the HS15
plus
. Load plotting paper, install the pen holder, and
set the tool force to .5.
2. Using the slew keys, position the carriage spindle approximately 1”
from the front edge of the plotting paper. Also, be sure that there are
several inches of paper extending past the carriage spindle and to the
left of the plotter.
3. Prepare two plot files. In the Plot Program, choose a left Start
Position and a right End Position for both plots before sending them
to the plotter.
Note: If both plot files have a left Start and left End Position they
may plot on top of each other.
Note: Entering an X,Y pre-position in the Plot Program is another
way to be sure that plots done in the
RUN CONT
mode will not plot
on top of each other. (See
GRAPHIX ADVANTAGE
Reference
.)
4. Press the
RUN CONT
key. Both jobs will plot without going off-line
between them.
