13
MATERIALS AND TOOLS
Material Products
The HS15
plus
uses the same plotting materials as all Gerber plotters.
Gerber vinyl products in high performance or intermediate grades are
translucent, reflective, or metallic and come in a wide range of colors.
Also available are direct cut silk screen, ruby photo film, paint masking
material, rubber sandblast stencil material, and heat transfer materials.
Consult your Gerber distributor for further information about available
materials, colors, and prices. Always insist on Gerber authorized
materials for highest quality results.
Loading Material
To load material
CAUTION: You can load material into your HS15
plus
plotter with a
tool installed, but it is preferable to load material with no tool in the
carriage. Otherwise, damage can result to the blade.
1. Slide the roll of material to be used onto the roll holder. Pull the end
of the material away from and over the top of the tensioner toward
the plotter, as shown.
