Gerber HS15 Plus - Run Single Key for Single Jobs; X08 Cut Test

34 HS15
plus
RUN SINGLE KEY
Use
RUN SINGLE
to plot a single job. This plot mode allows the
operator to reposition material between jobs and/or to pen plot using
paper before cutting vinyl.
RUN SINGLE
may be used with either swivel
knife mode or tangential knife mode.
Plot
1. Press
SWIVEL KNIFE
to select a knife mode. (For swivel knife
mode, the light over the
SWIVEL KNIFE
key is on. For tangential
knife mode, the light is off.)
2. Press
RUN SINGLE
. The light over the
RUN SINGLE
key comes on
and the HS15
plus
plots a single job. If other plot files are received
from the
GRAPHIX ADVANTAGE
while the first job plots, then a
waiting list (called
queue
) of these jobs is created in the
GRAPHIX
ADVANTAGE
.
The HS15
plus
returns to the off-line status after the job plots. It remains in
the knife mode selected.
The HS15
plus
waits for the operator to press the
RUN SINGLE
key again
to plot the next job. If other jobs are lined up in the queue, the green
lights above the two Run keys will flash.
Controlled Stop
Use
RUN SINGLE
(or
RUN CONT
) to pause plotting and check the
current job.
1. During a job, press the Run key which is currently selected (lit). The
HS15
plus
stops the plot at the next logical break in the program.
Note: The slew keys may be pressed to maneuver the carriage or
material. However, when the Run key is pressed again to exit the
pause mode, the plotter will return the carriage and material to the
point where the job was paused.
2. Press the same Run key to resume plotting at the exact same point.
RUN
SINGLE
