22 HS15
plus
Pounce Wheel Holder
Pouncing is a technique used to create an outline for a sign that will later
be hand-painted. It can also be used for vinyl character alignment on a
15-inch plotter when the job is much longer. The pounce wheel is
designed to pounce (perforate) holes either perfectly aligned or off-
center to the direction of travel. Select
CUT
in
VIEW/PLOT/CUT
at the
GRAPHIX ADVANTAGE
when you desire pouncing.
CAUTION: The pounce wheel may be used only in tangential
knife mode. Pouncing in swivel knife mode will tear the paper.
ALIGNED HOLES
There are two keyway slots on the barrel of the pounce wheel holder.
The standard keyway aligns the pounce wheel with the drum axis. Use
this position to produce small holes in lightweight paper or for light
dusting applications.
OFF-CENTER HOLES
The second keyway holds the tool at 11 degrees off-center to the
direction of tool travel. Using the pounce wheel in the angled position
causes the points to drag slightly as the wheel moves forward. This
produces larger, slightly elongated holes suited for heavy or clay-coated
paper and for bold dusting applications.
PLOTTER SPEED
In the straight (aligned) position, the pounce wheel works best at
reduced plotter speeds. The angled (off-center) position produces
distinctive holes at any plotting rate up to full speed. See the
GRAPHIX
ADVANTAGE
Reference
for more information on controlling the plotter
speed.
POUNCE WHEEL HOLDER INSTALLATION
To install the pounce wheel holder
1. Select the pounce wheel holder from the tool rack attached to the
rear cover.
