32 HS15
plus
To use slow slew
1. To select slow slew mode, press the
SLOW
key. You will hear a
single beep indicating the plotter is in slow slew mode.
2. When you press a slew key, the drum or carriage will move at a very
slow speed.
Fast slew
For faster slewing, hold down the left or right slew keys for more than 2
seconds and slewing begins moving at a higher speed. The plotter will
beep as the plotter speeds up. The faster speed allows material to be
moved through the plotter at a much faster rate.
To use fast slew
1. To return to normal mode, press the
SLOW
key again. You will hear
two beeps indicating the plotter is in normal slew mode.
2. Hold down a left or right slew key for more than 2 seconds, and the
drum will ramp up to a high speed as long as you hold the key down.
SWIVEL KNIFE KEY
CAUTION: Be sure that the knife you use matches the mode you
select.
The
SWIVEL KNIFE
key controls the selection of swivel knife mode or
tangential knife mode. The swivel knife is for faster speeds than the
tangential knife.
Note: When doing demanding jobs where high accuracy is desired
(such as Repeats, EDGE jobs), Gerber recommends that you use
tangential knife mode rather than swivel knife mode.
When swivel knife mode is selected, the light over the
SWIVEL
KNIFE
key is on.
If tangential knife mode is desired,
the light must be off
. Press
SWIVEL KNIFE
to turn the light on and off.
SWIVEL
KNIFE
