Special Diagnostics 41
SQUARE/CIRCLE TEST PLOT
To plot the Square/Circle Test Plot
1. Load vinyl and install the knife holder (tangential or swivel).
2. Press
SLOW
key to access diagnostic.
3. Select swivel or tangential knife mode according to the knife holder
loaded.
4. Press
RUN SINGLE
to plot once or
RUN CONT
to plot continuously.
5. Compare the test plot to the illustration below. If they do not look
the same, call Gerber Field Service.
