8 HS15
plus
Connecting the Plotter
CAUTION: Turn off power and unplug the power cord at both
the
GRAPHIX ADVANTAGE
and the plotter.
1. Insert the 9-pin connector at the end of the RS-232 cable into the 9-
pin RS-232 connector on the back of your
GRAPHIX ADVANTAGE
.
This connector is normally labeled
Plotter
or
COM Port 2.
2. Carefully align all pins. Use the connector thumb screws to secure
the cable to the
GRAPHIX ADVANTAGE
3. Insert the 25-pin connector at the end of the RS-232 cable into the
25-pin RS-232 connector on the back of the plotter.
4. Carefully align all pins. Use the connector thumb screws to secure
the cable to the plotter.
Note: If a plotter is already installed in the
PLOTTER
port on the
GRAPHIX ADVANTAGE
, use the
TABLET
port to install a second
plotter.
Communication Parameters
If you are connecting the HS15
plus
to a system other than the
GRAPHIX
ADVANTAGE
, the plotter uses these RS-232 communication parameters:
Communication Parameters
9600 Baud
No Parity
8 Data Bits
1 Stop Bit
Xon/Xoff Flow Control
