Materials and Tools 25
To install a knife holder
1. Load vinyl or other material.
2. Select the knife holder that matches the knife mode you want to use.
3. A plastic lift washer is used to reduce friction between the tool
holder and the lift fork of the carriage spindle during operation.
There should be one installed on the knife holder. If not, slip a lift
washer from the tool kit over the barrel and slide the washer to the
top of the holder.
CAUTION: Carefully install the knife holder, taking care not to
strike the tip of the blade against the bore of the carriage
spindle.
4. A slot, or keyway, in the barrel of the knife holder ensures proper
orientation. If necessary, rotate the knife holder until it drops
completely into the carriage spindle.
5. When the knife holder is in place, swing the tool force arm and snap
it into place over the tool cap.
6. If using the vinyl included with the HS15
plus
plotter, start with a tool
force setting of 1. Approximate tool force settings for cutting other
vinyl materials are listed in the following chart. (See the
HS15
plus
Tool Force Settings
Reference Card
.)
