Gerber HS15 Plus - Page 73

Appendix 65
HS15
plus
Plotter Parts List
Number Part Description
48 Drum Clamp
49 .375 x .625 x .032 Spacer
50 Retainer E-Ring
51 Screw 4-40 x .438
52 Screw 8-32 x .375
53 Washer Lock #8
54 Washer Flat #8
55 Spring CPRSN .042 x .48 x .625 (Drum)
56 Bail Arm Screw
57 Ball Bushing Assy.
58 Nut 10-32 x .13
59 Screw Mod. 10-32 x .5
60 Roller Assy.
61 Lifter Bar
62 Screw 4-40 x .375
63 Washer
64 Tape Terminal Block
65 Sensor Brkt, Screw 2-56 x .375
66 Clamp, X Gear
