Replacing a hose to a hose pump
This may only be done by authorized personnel.
Before starting work, make sure that the machine is isolated from the electric
power supply.
There are three grades of hose for installation in the pump, depending on the detergent
used. For article numbers see the spare parts list.
Remove the cover (3) by unscrewing screw A.•
Disconnect the hoses at connections B and C.•
Take out the entire unit including hose (2) (a complete spare parts kit).•
Install the new unit. •
Retthecover.•
B C
A
V1043
