Replacing a temperature sensor
This may only be done by authorized personnel.
The machine is connected to the electricity supply and some components are live.
Temperature sensors in
dryer
In wash chamber and dryer
Remove the old temperature sensor by pulling it out of the seal. •
Push the new sensor in through the seal.•
It is important that the sensor does not penetrate too far into the chamber,
since it may be damaged in service.
After replacing a sensor in the chamber, check that the controlling and inde-
pendent sensors show the same temperature. If not, calibrate as described
under Calibration.
In a booster tank
Remove the old temperature sensor by unscrewing the gland and pulling the sensor out. •
Push in the new sensor and tighten the gland. •
Temperature sensors
in wash chamber
Temperature sensors in
booster tank
V1562
