Getinge 86 SERIES Technical Manual

<Doc_TEC><Doc_502606900><Rel_B><Lang_GB>
Page 86 of 174
Differential pressure gauge for dryer
To calibrate the differential pressure gauge for the dryer, proceed as follows.
1. Connect a PC with the CS 1000 program installed to the disinfector.
2. Close the machine doors.
3. Connect an external differential pressure gauge in parallel with the existing gauge on
the machine. Zero the external differential pressure gauge.
4. Start CS 1000 and choose Settings/Calibration/Analog Input Automatic...
5. Click Dryer pressure (A) and then Calibrate (B).
V1573
V1563
A
B
