Conductivity measurement (extra equipment)

ConductivityismeasuredwithequipmentfromEndress+Hauser. (If the machine is

equippedwithamonitoringsystem,theconductivitymustbemeasuredasdescribed

under Conductivity measurement in Chapter 9.)

This may only be done by authorized personnel.

Function in washing process

Theconductivitymetermonitorsthequalityofthewaterinthenalrinse,independently

of the process control.

Iftheconductivityinthenalrinseishigherthatthepresetvalue,themachineisemp-

tiedandthenalrinseisrepeatedautomatically.

If, after three repetitions, the conductivity is still above the preset value, the process is

stopped and fault code 11 appears on the display.

Measuring range

The normal measuring range is 0-20 µS/ cm

Calibrating the conductivity equipment

Seemanual:LiquisysCLM223,fromEndress+Hauser.

Theconductivityequipmentiscalibratedatthefactorybyspecifyingtheexactcellcon-

stant; see below.

7.1 Default

7.2 Default

7.3 Set SP1 Limit 15 µS/ cm*

Set Hi= Max. contact

Rest default

*The user chooses the value during process validation.

7.4 Default

7.5 Set 20 µS/ cm

Rest default

7.6 Default

7.7 Setcellconstantasvalueincerticate98.7%**

Rest default

  **Takethegurefromthecerticateforthemeasuringcell.
