Getinge 86 SERIES Technical Manual

Page 69 of 174
<Doc_TEC><Doc_502606900><Rel_B><Lang_GB>
7. Move jumper X29 on the board for the PACS 300 control system from Normal to
Test. Check that jumper X28 is in the Flash position and that jumper X30 is in the
ON position.
8. Switch on the power to the machine with the main switch. One of the following
three menus appears on the display:









V1544
X29
X30
X28
GETINGE
RAM OK
GETINGE PACS 300
Version X.XX
GETINGE BOOT 1179-61
RS232 0=0003 - FAIL
or
or
9. Start Flashloader from PC.
