8
GSH130363A*
GSH130483A*
GSH130603A*
GSH130484A*
GSH130604A*
Cooling Capacity, BTUH 35,000 45,000 55,500 45,000 55,500
Compressor
R.L. Amps 8.3 12.4 17.3 5.8 6.7
L.R. Amps 48.0 88.0 123.0 44.0 49.5
Loss of Charge Pressure Switch
Open / Close 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG
Condenser Fan Motor
Horsepower 1/4 1/4 1/6 1/4 1/6
F.L. Amps 1.6 1.6 1.1 0.8 0.6
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 7/8" 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge 188 223 233 223 233
Design Subcooling Cooling (°F) 9 +
39 + 39 + 39 + 39 + 3
Power Supply 208/230-60-3 208/230-60-3 208/230-60-3 460/60/3 460/60/3
Minimum Circuit Ampacity
(1 )
12.0 17.2 22.7 8.0 9.0
Maximum Overcurrent Device
(2)
20 20 40 15 15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 207 225 266 225 266
GSH130[36-60]3*
GSH130[48-60]4*
HEAT PUMP SPECIFICATIONS
(1)
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection: Must use fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units that require a TXV Kit to be installed on the indoor coil: PLEASE NOTE: THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT
NOT THE INDOOR COIL
