Annex 2. Alarms Definitions
RF Alarms
Alarm ID
Description
41A1
Power under user-defined threshold
41A2
Power above user-defined threshold
41A3
MER under user-defined error threshold
41A4
CBER above user-defined threshold
41A5
C/N under user-defined threshold
41A6
VBER above user-defined threshold
41A7
ECHO above user-defined threshold
41A8
Spectrum out of mask
41A9
LDPCBER DVB-T2 under user-defined threshold
41AA
BCHBER DVB-T2 under user-defined threshold
41AB
PreBER DVB-C under user-defined threshold
41AC
PostBER DVB-C under user-defined threshold
41AD
LDPCBER DVB-C2 under user-defined threshold
41AE
BCHBER DVB-C2 under user-defined threshold
41AF
CBER DVB-S under user-defined threshold
41B0
VBER DVB-S under user-defined threshold
41B1
LDPCBER DVB-S2 under user-defined threshold
41B2
BCHBER DVB-S2 under user-defined threshold
41B3
CBER ISDBT under user-defined threshold
41B4
VBER ISDBT under user-defined threshold
41B5
PreBER QAMB under user-defined threshold
41B6
PostBER QAMB under user-defined threshold
41B7
Offset above user-defined threshold
41B8
Echo out of mask
4193
MER under user-defined warning threshold
42A1
Demodulator locked
42A2
Demodulator unlocked
42A3
ASI signal Lock
42A4
ASI signal Unlock
ETSI TR 101 290 V1.3.1 Priority 1
Indicator
Alarm ID
Description
TS_sync_loss
11A1
Loss of synchronization in several consecutive
packets
Sync_byte_error
12A1
Synchronization byte other than 0x47
PAT_error
13A2
Found in PID 0 another table that is not PAT
13A3
Scrambling control field is not 0 in the packet with
PID 0
13A4
The PAT does not exist. The searching time is
displayed in alarm 1.3.A.1
Continuity_count_error
14A1
Continuity error in a packet
PMT_error
15A1
The PMT does not occur every 0,5 seconds
15A2
Scrambling control field is not 0 in the packets that
transport the PMT
PID_error
16A1
Referred PID does not occur for a user specified
period
