Gsertel RCS 100 User Manual

RCS User Manual
7
Specifications
RCS 50
RCS 100
RCS 400
General Specifications
Display
Graphic LCD STN. Resolution:256x64
Format
1U 19” rackable unit
Weight
3250 g.
Dimensions
448x380x43.3mm
Operating temperature
-5ºC to 45ºC (23ºF to 104ºF)
Storage temperature
-20ºC a 70ºC (-4ºF a 158ºF)
Humidity
5% to 95% non-condensing
Interfaces
Web and keyboard
Power supply
100-240 VAC 50-60MHz 1.4A
Storage capacity
500 GB
1 TB
Internal GPS
-
Option 902566
Technical Specifications
Frecuency
Range
47-862MHz (Demodulation)
5-1000MHz (Spectrum)
Resolution
100 KHz
Tuning
Channel and frequency
Inputs
RCS 50
RCS 100
RCS 400
RF
1 x N 50Ω connector
1 x N 50Ω connector
4 x N 50Ω connector
ASI
1 x BNC 75Ω connector
(option 902554)
1 x BNC 75Ω connector
4 x BNC 75Ω connector
Synchro
-
1 x 1pps BNC 50Ω connector
-
1 x 10MHz BNC 50Ω connector
IP
-
Option 902518
Outputs
ASI
1 x BNC 75Ω connector
A/V
1 x HDMI 1.4
Spectrum Analyzer (Option 902511 only for RCS100 y RCS400))
Span
-
10, 20, 50, 100, 200, 500, 1000 MHz
Scale
-
-100 dBm to 20 dBm
Max. and Min. Hold
-
√
Marks
-
2
Mask
-
√
RF Analysis
Demodulation
ETSI EN 300744 (DVB-T), ETSI EN 302755 (DVB-T2)
Constellation
QPSK, 16, 64, 256QAM
U.A.L. Technology (Universal
Auto Lock)
Automatic detection of signal characteristics and modulation parameters
Power
-100 dBm to 20 dBm
C/N
Up to 50 dB
MER
Up to 40 dB

Gsertel RCS 100 Specifications

General

Brand	Gsertel
Model	RCS 100
Category	Microphone
Language	English
