RCS User Manual
41
In the left-hand column there is a list of the profiles as defined in the ETR290, with their
corresponding parameters: T is the total period of time, N is the number of windows of time and t is
the duration of each window of time.
The size of the elements refers to the bytes taken into account. 188 is the total number of bytes,
and payload are the bytes corresponding to the information. In the case of SI/PSI tables, the bytes
taken into account will be all the bytes of the table. In the case of audio and video, the bytes taken
into account will be the P packets.
The user can choose the profiles that he wants to activate for the transport streams, for the tables,
for the Audio/Video services and for other services.
See section 3.- TS Analysis to see how to apply the profile to each service.
1.5.3.- Profiles shortcut
You can easily see the profiles assigned to the selected channel from any measurements window,
by clicking on the Profiles button at the top bar of the window:
Then, a popup window will be open showing all the alarms profiles assigned to the selected
channel. You can click on View Profile link to go to the Alarms Profiles window.
