1.5.- Profiles
1.5.1.- Alarms Profiles
Using this window, you can set up the alarms that the system will generate.
There are several types of alarms: RF, ASI, IP, ETR290, Services, PID Blacklist, PID Bitrate, and
Quality of Service.
In fact, the PID Blacklist is not a list of alarms. It is a list of PID that the user wants to ignore, that is,
the alarms generated in the PID included in the Blacklist will not be activated, so the user will not
see them.
You can configure as many alarms profiles of each type as you want (max. 256 profiles). The RCS
allows to assign a different profile of each type to each channel (see section 1.3.1- Channel Plans),
except the PID bitrate ones, that are assigned to services.
Please check Annex 2.- Alarms Definition to find out all the alarms collected in the RCS.
The image bellow shows the alarms profile configuration.
