RCS User Manual
88
Local Features
Info
By using the keyboard of the RCS, the user can check the information of the equipment, as well as
setup the IP and the language. You can also check the status of the RF inputs, and shut down your
equipment in an orderly manner.
The information relating to the network is shown on the left part of the screen: IP, GW and mask.
The information relating to the equipment is shown on the right: firmware version, serial number and
date and hour.
Pressing the Setup button, the user can setup the IP and the language.
When the RCS starts, the display will show the Info menu. By default, the RCS shipped in DHCP
mode, so the IP will be selected automatically:
To enter a certain fixed IP, press the Setup button and select the STATIC option. Then you must
enter an IP address within the range of your network, by using the buttons.
To check the status of the RF inputs, press the button to select the Status menu:
NETWORK
IP: 192.168.010.164
GW: 192.168.010.249
MASK: 255.255.255.000
System Info
Ver. 4.01.00088
S/N 01160216400003
Date
18-05-17 11:06
INFO
EXIT
STATUS
DHCP STATIC
IP: 192.168.010.164
GW: 192.168.010.249
MASK: 255.255.255.000
Apply
Cancel
System Info
Ver. 4.01.00088
S/N 01160216400003
Date
18-05-17 11:06
INFO
EXIT
STATUS
NETWORK
IP: 192.168.010.164
GW: 192.168.010.249
MASK: 255.255.255.000
System status
T: 50 C
STATUS
EXIT
INFO
INPUT STATUS
RF1: RF ALARM
RF2: OK
RF3: OK
RF4: DISABLED
