SERVICE AND REPAIR
Switch track GH
Installation of Cover kit 1
Important
When installation PCB and cables etc. protection against
static electricity must be used.
1 Switch off transformer supplying switch track before
removing plate.
2. Remove the screws holding the change plate and
remove the plate.
Remove the screws holding the cover and remove the
cover.
Disconnect the transformer cables from the PC board and
Remove the cover.
