Guldmann GH - Types of Rail; Gh3 & Gh3

© Guldmann GB/US-09/2016 • #550376_3
10
GENERAL INFORMATION
There are three different types of rails:
Rail A, B and C.
Rail A are normally used in single-track systems.
The overall height of the rails in a room-covering system
can vary from 99 mm (4") for two Rail A (traverse rail
mounted between Rail A parallel rails, System “A” ) to 381
mm (15") including bracket for two Rail C (Rail C parallel
rails with underhanging Rail C traverse rail, System “I”).
The traverse rail can be mounted in between the parallel
rails, it can be underhung or be a combination of the two
solutions i.e. system "M"
Rail A Rail B Rail C Rail A Rail B Rail C
Weight: 2.6 kg/m Weight: 5.0 kg/m Weight: 6.0 kg/m
(5.72 lbs/m) (11 lbs/m) (13.2 lbs/m)
170 mm
(6
2
/
3
")
125 mm
(5")
58,5 mm
(2
1
/
4
")
62 mm
(2
1
/
2
")
62 mm
(2
1
/
2
")
62 mm
(2
1
/
2
")
Max
projection
Max distance between
supporting points
Available lengths
Meter 0,23 0,7 1,2 1,0 1,25 1,5 1,75 2,0 3,0 3,5 4,0 4,5 4,75 5,25 6,0 6,25 6,75 7,25 8,0 1 2 3 4 5 6 7 8
Inch
9
27 47 40 50 60 70 80 120 140 160 180 190 210 234 250 270 290 320 40 80 120 160 200 240 280 320
Rail Max 205 kg (450 lbs)
A
x x x x x x x x
B
x x x x x x x x
C
x x x x x x
Rail Max 255 kg (560 lbs)
A
x x x x x x x x
B
x x x x x x x x
C
x x x x x x
Rail Max 300 kg (660 lbs)
A
x x x x x x x x
B
x x x x x x x x
C
x x x x x x
Rail Max 350 kg (770 lbs)
A
x x x x x x x x
B
x x x x x x x x
C
x x x x x x
Rail Max 375 kg (825 lbs)
A
x x x x x x x x
B
x x x x x x x x
C
x x x x x x
Rail Max 500 kg (1100 lbs)
A
x x x x x x x x
B
x x x x x x x x
C
x x x x x x
Types of rail
GH3 & GH3+
