© Guldmann GB/US-09/2016 • #550376_3
129
TECHNICAL DRAWINGS
Pos. no. Part Drawing/Item no.
1 Wire reservoire assembly, spare part 550123
2 Connection trolley, spare part 550545
3 Beltdrive, spare part 550546
4.1 Strap, spare part 550547
4.2 Strap for corrosive surroundings 554305
5.1 Motor safety PCB 2010, spare part incl. Cables 550548
5.2 Motor safety PCB 2010, spare part 550593
6 Communication PCB, spare part 550549
7 IR PCB, spare part 550551
8 Wiring complet GH3, electronic lowering 550769
9 Bottom cover, spare part 550553
10 Trolley assembly, spare part 550560
11 GH3 cover plate, spare part 550561
12.1 Finger protection plate with hole, spare part 550562
12.2 Finger protection plate, spare part 550563
13 Safety control mechanics, spare part 550564
14.1 Handcontrol GH3+, spare part 550571
14.2 Handcontrol GH3+, Drive motor, spare part 550773
15 Charger PCB, spare part 550573
16 Ni-mH Battery Pack, 24V/2,8Ah, spare part 550574
17.1 Hoist cover top basic, spare part 550575
17.2 GH3 top cover, loadcell, spare part 550576
17.3 GH3 top cover + 1 charger PCB, assy 550041
17.4 GH3 top cover + 2 charger PCB, assy 550180
18 Belt GT 3 mm Pitch, 9 mm width, 414 mm length, spare part 550580
19 Trolley assembly with pickup, spare part 551456
20 Trolley centering clips 10 pcs. pack, spare part 554029
21 Pick-up assembly, spare part 552534
22 Trolley, drive, assy, spare part 554197
23 Trolley guide, 50 pcs. package 551324
24 Set op 2 covers, drive motor, spare part 551504
25 PCB Motor AUX, spare part 552627
Spare part overview
GH3+
