TECHNICAL DRAWINGS
Spare part overview
GH3
Pos. no. Part Drawing/Item no.
1 Wire reservoire assembly, spare part 550123
2 Connection trolley, spare part 550545
3 Beltdrive, spare part 550546
4 Strap, spare part 550547
5.1 Motor safety PCB 2010 incl. Cables, spare part 550548
5.2 Motor safety PCB 2010, spare part 550593
6 IR PCB, spare part 550551
7 Wiring complet GH3, electronic lowering 550769
8 Bottom cover, spare part 550553
9 Trolley assembly, spare part 550560
10 GH3 cover plate, spare part 550561
11.1 Finger protection plate with hole, spare part 550562
11.2 Finger protection plate, spare part 550563
12 Safety control mechanics, spare part 550564
13.1 Handcontrol GH3, spare part 550572
13.2 Handcontrol GH3, Drive motor, spare part 550774
14 Charger PCB, spare part 550573
15 Ni-mH Battery Pack, 24V/2,8Ah, spare part 550574
16.1 Hoist cover top basic, spare part 550575
16.2 GH3 top cover, loadcell, spare part 550576
16.3 Hoist cover top, 1 drive motor, spare part 551503
16.4 GH3 top cover + 1 charger PCB, assy 550041
16.5 GH3 top cover + 2 charger PCB, assy 550180
17 Belt GT 3 mm Pitch, 9 mm width, 414 mm length, spare part 550580
18 Trolley assembly with pickup, spare part 551456
19 Pick-up assembly, spare part 552534
20 Trolley centering clips 10 pcs. pack, spare part 554029
21 Trolley, drive, assy, spare part 554197
22 Set op 2 covers, drive motor, spare part 551504
23 PCB Motor AUX, spare part 552627
