TECHNICAL DRAWINGS
Spare Part overview
GH1 & GH1 Q
Pos. no. Quantity Part Drawing/Item no.
1 1 Sidecover, zebra & fish, spare part 551109
2 2 Trolley assembly GH1, spare part 551099
3 1 Hoist cover, top, GH1, spare part 551107
4 2 Rubber Sealing, set of 2, spare part 552884
5 1 Belt transmission cpl. GH1, spare part 551105
6 1 Belt GT 3mm pitch, spare part 550580
7 1 Safety control assembly, mechanics, spare part 550564
8 1 Handcontrol Assy, Hoist GH1, spare part 551104
9 1 Strap, spare part 550547
10 1 Ni-mH Battery pack 24V/2.8Ah, spare part 550574
11 1 Sealing for strap access, spare part 551112
12 1 Hoist cover, buttom, GH1 2012, assembly, spare part 551102
13 1 Charger signal cable, GH1 and GH1 F, spare part 551100
14 1 PCB and Battery unit assembly, spare part 552881
15 1 Fasteners, kit for GH1, spare part 551237
16 2 Connection trolley GH1 + GH1 F, spare part 552885
17 1 Power supply 36V DC, spare part 551244
18 1 Docking portable assembly, spare part 552880
19 1 Motor safety PCB 2010, spare part 550593
20 1 Bracket for charger, spare part 551325
21 1 Quick release GH1 Trolley 552730
22 1 Charger PCB, spare part 550573
23 1 Quick release hoist part, spare part 552731
24 1 Sidecover, white/yellow, spare part 554301
