TECHNICAL DRAWINGS
Spare Part overview
GH1 F
Pos. no. Quantity Part Drawing/Item no.
1 1 Strap, spare part 550547
2 1 Safety control assembly, mechanics, spare part 550564
3 1 Charger PCB, spare part 550573
4 1 Ni-mH battery pack 24V 2,8Ah, Spare part 550574
5 1 Belt GT 3mm Pitch, W=9 mm, 550580
6 1 Motor safety PCB 2010, spare part 550593
7 1 Charger signal cable, GH1 & GH1F, spare part 551100
8 1 Hoist cover, bottom, GH1 2012, assemblt, spare part 551102
9 1 Belt transmission cpl. GH1, spare part 551105
10 2 Side cover, zebra & fish, spare part 551109
11 1 Trolley GH1 F 551165
12 1 GH1 F, Top assembly, spare part 551233
13 1 Travelling trolley GH1F/GH2F, sparepart 551234
14 1 Handcontrol GH1 F, spare part 551236
15 1 Fasteners, kit, spare part 551237
16 1 Cover for winch, spare part 551238
17 1 Top cover, GH1F, Spare part 551239
18 1 Cable install. unit, AUX & MS, spare part 551241
19 1 Cable connection between MS & AUX, spare part 551242
20 1 Power supply 36V DC, spare part 551244
21 1 Trolley lock, GH1F, spare part 551245
22 1 Winch, complete, spare part 551247
23 1 Bracket for charger, spare part 551325
24 1 PCB Motor AUX, spare part 552627
25 1 PCB and Battery unit ass., spare part 552881
26 2 Connection trolley ,GH1 & GH1F, spare part 552885
27 1 Side cover, White / Yellow, spare part 554301
