SERVICE AND REPAIR
Hand control
display
Fault description Fault mitigation – Technician
Fault 18/1 Communication fault – Twin hoist (18) Check cables and connection between PCB on
leader hoist (J10/J11 on 16) and follower hoist
(J10/J11 on 18)
Check battery voltage on (18), minimum 16 volt.
Check jumper settings on (18).
• Replace PCB (16) or (18).
Fault 81/1 Communication fault – Com module (81) Check cables and connection to Com module
(J105 or J5 on 81 to J2 on 16)
• Check jumper setting on (81)
• Replace (81)
Fault 82/1 Communication fault – Com module follower
twin hoist (82)
Check cables and connection to Com module
(J105 or J5 on 82 to J2 on 18)
• Check Jumper setting on (82)
• Replace (82)
Fault 32/1 Communication fault – Aux drive motor (32) Check cables and connection to aux module
(J2 on RS485 to J3 on 16)
• Check Jumper setting on (32)
• Replace (32)
Fault 16/22 Hardware overcurrent – leader (16) • Replace motor (16)
• Replace PCB (16)
Fault 17/22 Hardware overcurrent – follower (17) • Replace motor (17)
• Replace PCB (17)
Fault 18/22 Hardware overcurrent – leader – twin hoist (18) • Replace motor (18)
• Replace PCB (18)
No charging 16 No charging on from leader charger Check power form charging liner and power supply
Check connection between charger PCB (J4) and
motor safety PCB (J20 on 16)
Check connection between battery and charger (J3)
• Change charger PCB
No charging 17 No charging on from follower charger Check connection between the two charger PCB’s
(J2 to J2)
Check connection between charger PCB (J4) and
motor safety PCB (J20 on 17)
Check connection between battery and charger (J3)
• Change charger PCB
No charging 18 No charging on from leader charger – follower
hoist – Twin hoist
Check power form charging liner and power supply
Check connection between charger PCB (J4) and
motor safety PCB (J20 on 18)
Check connection between battery and charger (J3)
• Change charger PCB
