System Overview
HTX30 Product Manual
2-2
Installation steps
Step
Refer
Section
Description
1
Component overview
1.2
Become familiar with the main components of the
system
2
Design considerations
2
Consider design and layout environmental requirements
3
Component installation
3
Install components and run cabling between modules
4
Post-installation checks
3.3
Check modules are correctly installed
5
Pre-launch setup
4.1
Configure the control system
6
Pre launch checks
4.4
Make sure the system is correctly configured
7
Preparing for launch
4.5
Do any final checks
8
Sea trialing
4.6
Check system operation on the water, do final setup and
checks
9
Vessel registration
4.8
Register the vessel
Component overview
The blue ARROW control system consists of several electronic modules and interconnecting cabling.
The following are included as part of HamiltonJet's base scope of supply. Optional modules for advanced and
specialised configurations are also available. Optional modules are described later in this guide.
Base modules.
 One station control panel per control station.
 One jet interface module per jet.
 One engine interface module per engine.
Control input devices.
 One dual lever module per control station.
 One helm wheel module per control station.
 One Mouseboat manoeuvring controller per control station.
Miscellaneous.
 One alarm sounder per station control panel.
 Interconnecting cabling for all modules.
 Network terminations.
 Module connection details can be found here (► page 4-5).
