Jet loom pin assignments
The following tables list pin assignments for the jet loom, which connects the Jet Interface Module (JIM) to
various sensors, actuators and power supplies.
JIM connector to steering feedback sensor connector
Signal JIM connector pin
number
Wire colour or number Steering feedback
sensor connector pin
number
5 V (1)
23
1
1
0 V (1)
11
2
2
Signal (2)
31
3
3
Signal (1)
12
4
4
0 V (2)
5
5
5
5 V (2)
18
6
6
NA
NA
Green (not used)
NA
JIM connector to RPM sensor connector
Signal or voltage
JIM connector pin
number
Wire colour or number
RPM sensor connector
pin number
0 V
22
Blue
3
12 V
20
Brown
1
RPM
9
Black
4
NA
NA
White (not used)
NA
JIM connector to level and temperature sensor connector
Signal
JIM connector pin
number
Wire colour or number
Level and temperature
sensor connector pin
number
0 V
8
1
1
5 V
32
2
5
Level
33
3
3
0 V
6
Green and yellow
4
Temperature
19
4
6
NA
NA
NA
2
JIM connector to reverse feedback sensor connector
Signal or voltage
JIM connector pin
number
Wire colour or number
Reverse feedback
sensor connector pin
number
5 V (1)
21
1
1
0 V (1)
4
2
2
Signal (2)
30
3
3
Signal (1)
10
4
4
0 V (2)
16
5
5
5 V (2)
28
6
6
NA
NA
Green (not used)
NA
