Hamilton Jet HTX30 - SCP Parameters

Appendix
HTX30 Product Manual
8-52
SCP parameters
Top level parameters
Name
SCP text
Description
Min
Max
Default
Units
Access
Number of jets
NumJt
The number of jets expected to be in the system. Set
explicitly to detect a mis-installed twin jet system that
looks like a single jet.
1
2
2
C
Has an autopilot
Autp?
Set if an autopilot is connected to this SCP. The
autopilot itself is set up later in the Autopilot group.
0
1
0
C
Setup pass code
Paswd
The user level password used to enter setup.
0
999
113
U
Registration code A
RegCA
Registration code 'A' for this system
0
999
0
U
Registration code B
RegCB
Registration code 'B' for this system
0
999
0
U
Next registration is
B
NxtRB
Indicates the next 'free' registration code to write to
0
1
0
F
Sounder profile
SndrP
Profile to use for the external sounder output. Changes
how the sounder drives in response to an alarm and
other system events. 'Events' causes all events to sound.
'Alarms' causes only alarms to sound. 'Logger' sets the
line whenever any alarm is present:
 Ev - Events
 Al - Alarms
 Lo - Logger
C
Helm curve
HlmCv
May be used to desensitise the helm around the ahead
position. zero turns off the helm curve, so a half turn on
the helm results in half deflection on the jet nozzles.
Higher numbers flatten out the response so that at the
highest setting a half turn results in approximately 10%
deflection. Full lock is still available if the helm is turned
to full lock.
0
6
0
U
Throttle curve
ThrCv
May be used to get finer throttle control at high RPM.
Higher numbers give more resolution at the high end.
0
6
0
U
DLM-C reverse
sector fraction
DlmCF
The width of the reverse sector for any DLM-Cs at this
station. '20' makes the first 20% of the travel from the
detent control the reverse and the remaining 80%
control the throttle.
5
50
20
%
C
Load ship values
Load
U
Software version
SWVer
U
Boot block software
version
BbVer
F
Amendment
Amend
U
PCB amendment
PCBAm
F
