Hamilton Jet HTX30 - Cabling Requirements and Installation

HTX30 Product Manual
System Design
3-3
Cabling
Once the position of the modules has been determined, measure the lengths of the cables required between
the modules.
Hamilton Jet supplies cables in the following lengths.
Cable type
Length (Mtrs)
Part #
Station control panel to station control panel
5
204378
8
204379
12
204380
Station control panel to jet interface module (port)
8
204375
12
204376
18
204377
Station control panel to jet interface module (starboard)
8
204381
12
204382
18
204383
Station control panel to external control interface, or
1
207341
Station control panel to JETanchor control module
3
207204
6
213387
9
213388
12
213389
Station control panel to auxiliary (autopilot)
3
204363
Station control panel to audio sounder
3
204364
Jet interface module to engine interface module (port)
3
204369
5
204370
9
204371
12
212417
18
207942
Jet interface module to engine interface module (starboard)
3
204372
5
204373
9
204374
12
212418
18
207943
Jet interface module to jet interface module
3
204365
5
204366
10
204367
15
207649
Between control input devices
2
342856
5
342929
Additional cables for single jet installations only
Station control panel to jet interface module (yellow SCP connector)
8
204375
12
204376
Station control panel to jet interface module (blue JIM connector)
8
208095
12
208097
JETanchor control module to external control interface
5
213391
