Hamilton Jet HTX30 - Installation and Commissioning Check Sheets; After Installation Checks

Appendix
HTX30 Product Manual
8-28
Installation and commissioning check sheets
After installation checks
Module and wiring checks
Completed
 Modules secure.

 Cables are correctly attached.

 Termination links on last control devices.

 Termination links on last SCP (unless an XCI or JACM is fitted).

 Autopilot correctly attached.

 JETanchor control module (JACM) correctly mounted (if fitted (► page 4-7)).

 JETanchor GPS antenna correctly mounted (if JETanchor is fitted (
►
page 4-
8)).

 All modules earthed to the vessel structure or bonding system.

Relocating or re-orientating the JETanchor control module (JACM) or GPS antenna after the
commissioning process can cause vessel control stability issues when JETanchor is engaged. If the
JETanchor control module or GPS antenna is moved or re-orientated after commissioning, the
JETanchor commissioning procedure must be repeated.
Power checks
Completed
 Normal power supply.
______V
 Backup power supply.
______V
 Power to JIMs from backup and normal supply.
Normal battery to port JIM voltage:
______V
Backup battery to port JIM voltage:
______V
Normal battery to starboard JIM voltage:
______V
Backup battery to starboard JIM voltage:
______V
 Supply voltage at SCP.
______V
 Power on system.

 Backup supply when normal lost.

 Normal supply when backup lost.

 SCP supply when port/starboard JIM supply lost.

