Appendix
HTX30 Product Manual
8-58
Sensor group
Short name: Sensr
Name
SCP text
Description
Min
Max
Default
Units
Access
Has DGPS
corrections
DGPS?
Set if the installation has a DGPS correction service
connected to the GPS. If set, an alarm activates if the
correction service is missing:
 0 = no DGPS connected.
 1 = DGPS connected.
0
1
1
C
Antenna X offset
X Off
GPS X offset from vessel origin.
-32000
32000
0
mm
C
Antenna Y offset
Y Off
GPS Y offset from vessel origin.
-32000
32000
0
mm
C
Antenna Z offset
Z Off
GPS Z offset from vessel origin.
-32000
32000
0
mm
C
JACM orientation
SkmOr
The JACM's orientation within the vessel. Affects roll
and pitch control:
 At = Facing STBD cables down.
 Po = Facing PORT cables down.
 Ah = Facing AHEAD cables down.
 As = Facing ASTERN cables down.
 De = On DECK cables aft.
 Dh = On DECKHEAD cables aft.
refer to section: JETanchor Control Module Installation
("JETanchor control module" on Page 4-7).
C
Waterjet group
Short name: W Jet
Name
SCP text
Description
Min
Max
Default
Units
Access
Jet model
JtMdl
Type of jet unit:
 21 = HJ213
 24 = HJ241
 27 = HJ274
 29 = HJ292 or HJX29
 30 = HTX30
 32 = HJ322
 36 = HJ364
 40 = HJ403
 42 = HJ421
 46 = HJ461
C
Jet X offset
jX
Fore/Aft distance of the waterjet thrust points from the
vessel origin (negative).
-20000
-500
-3240
mm
C
Jet spacing
jS
Distance between waterjet shafts.
500
20000
936
mm
C
Impeller rating
ImpRt
Impeller rating.
160
65500
186
W*100
C
Deadrise
Drise
Vessel deadrise at transom.
0
32000
0
milli
degrees
C
Zero speed
correction port
ZrSdP
Zero speed correction applied to the the reverse lookup
table for the port waterjet.
-15000
15000
0
%/100
F
Zero speed
correction starboard
ZrSdS
Zero speed correction applied to the the reverse lookup
table for the starboard waterjet.
-15000
15000
0
%/100
F
Maximum
JETanchor RPM
MxJAR
Maximum engine rpm that JETanchor can demand.
300
6000
1000
rpm
C
Maximum RPM
Maxim
Maximum engine rpm. This should match the equivalent
maximum rpm parameter set in each engine interface
module.
1300
6000
4000
rpm
C
