HamiltonJet
1
PORT
STARBOARD
ASTERN
AHEAD
NOTE: SOLENOID FUNCTION SHOWN FOR REFERENCE
7
10
8
6
5
PLUG &
0.6 ORIFICE
SUPPLIED WITH ITEM 1
318000 SHOWN (NO PRESSURE SENSOR)
TORQUE ITEM
7
TO 31Nm
TORQUE ITEM
8
TO 31Nm
TORQUE ITEM
10
TO 31Nm
TORQUE ITEM
6
TO 44Nm
TORQUE ITEM
5
TO 31Nm
14
PLUG &
0.3 ORIFICE
SUPPLIED WITH ITEM 1
M
13
11
10
94
1112
316196 SHOWN (WITH PRESSURE SENSOR)
TORQUE ITEM
13
TO 35Nm
TORQUE ITEM
10
TO 31Nm
TORQUE ITEM
4
TO 15Nm
TORQUE ITEM
9
TO 31Nm
4
3
2
SOLENOID VALVE ATTACHMENT
TORQUE ITEM
4
TO 15Nm
CAUTION: ENSURE O-RING'S
SUPPLIED WITH ITEM
2
ARE
FITTED
NOTES
REFER TO DRAWING 85144 FOR LOCTITE SPECIFICATION AND APPLICATION
1.
REFER TO DRAWING 85113 FOR FASTENER LUBRICATION AND TORQUE SPECIFICATION
2.
TABLE 2: BILL OF MATERIALS
316196 318000
PART No.
ITEM
DESC
DRAWING
1 1 213587 1
VALVE BLOCK - IHL HDM19597 - bA
213587
2 2 318402 2
SPOOL VALVE - WANDFLUH WDPFA04-ADB-V-4-G12/VD - PROPORTIONAL SOLENOID
N/A
6 6 203728 3
M5x40 A4-70 SKT-HEX CAPSCREW
N/A
3 3 64264 4
CARTRIDGE VALVE - SHUTTLE (DANFOSS BDSV-4-N-3-0)
N/A
2 2 203723 5
CARTRIDGE VALVE - SUN HYDRAULICS CKBD-XCN PILOT OPERATED CHECK
N/A
2 2 211763 6
CARTRIDGE VALVE - COUNTERBALANCE VALVE SET TO 1300 PSI (SUN #CBBA-LHN)
N/A
1 1 203725 7
CARTRIDGE VALVE - SUN HYDRAULICS LRBC-XHN MODULATING ELEMENT 200 PSI
N/A
1 1 320176 8
PLUG (HYDRAULIC) - SUN HYDRAULICS XZCCXXN T-162A CAVITY
N/A
1 1 318780 9
CARTRIDGE VALVE - RESTRICTIVE COMPENSATOR (SUN LPBC-XHN)
N/A
2 2 203724 10
CARTRIDGE VALVE - SUN HYDRAULICS NFBC-KCN NEEDLE
N/A
4 4 312008 11
HYD NIPPLE - RYCO M75LDSS1404 MALE/MALE M14 - 1/4" BSPP
N/A
2 2 316228 12
HYD NIPPLE - RYCO M75LSS-1806 3/8" BSPP MALE - M18 MALE NIPPLE
N/A
1
-
318410 13
SENSOR - PRESSURE - IFM EFECTOR PT5401 (4-20) 250bar
N/A
-
1 204210 14
PLUG (BSPP) - 1/4" SF1004N (MARTIN HYDRAULICS)
N/A
TABLE 1: CONFIGURATION(S) DEFINED ON THIS DRAWING
PART No.
DESCRIPTION
REV
MASS [kg]
316196
PROPORTIONAL VALVE BLOCK ASSY - - AVX HTX30
M
8.86
318000
PROPORTIONAL VALVE BLOCK ASSY - - bA HTX30
M
8.81
E
D
C
B
A
F
765
4
3
1
8
431
2
DOCUMENT TITLE
PROPORTIONAL VALVE BLOCK ASSY - ELECTRONIC CONTROLS - HTX30
3RD ANGLE PROJECTION
DRAWN TO HAMJET 085195
DWG No:
319161
REV:
M
This print is provided on a restricted basis and is not to be used
in any way detrimental to the interests of C. W. F. Hamilton and Co. Ltd.
DOCUMENT REVIEW:
ENGINEERING REVIEW:
REVISED:
SHEET SIZE:
A3
SCALE:
1:2
SHEET 1/1
UNTOLERANCED DIMENSIONS & SURFACE FINISH
GENERAL:
0.5
HOLES:
0.2
ANGULAR:
0.5
MACHINED SURFACE FINISH: Ra
6.3
µm
CHANGE SUMMARY
REVISION
M
REFER TO ECN
31776
FOR DETAILS
PLUGGED PORT "OR.P" SHOWN
A.HEA
H.THO
P.HAN
02-10-2019
2
UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS IN MILLIMETRES
REMOVE ALL SHARP EDGES & BURRS
5
02-10-2019
02-10-2019
A
B
C
D
E
STATE:
Released
To Next Page
