1.3 Envelope feeding
1.3.1 With the standard automatic feeder
- Fan the envelopes to separate them
- Bevel the edge of the stack
- Place the envelopes on the feed platform, with their upper edge
resting against the back of the feed platform.
- Ensure that the envelopes are stacked along the side and front
guides.
Adjustment of the rear guide (1)
Adjust the rear guide according to the envelope size. The bottom
envelope should rest in the "v" of the guide.
Adjustment of the side guide (2)
Adjust the side
guide by resting it
against the
envelopes without
pressing.
2
1
