Operation with a roll tape dispenser (RTD) 85
ORIG0140-85
4127718F/B
02/26/2007
(You may directly type on the MULTI LABEL keys with an
external scale, to get the labels).
- Remove the label by pulling upwards.
- Press the RTD label button to get the next label,
or press
START
STOP
(on the machine) to cancel label printing (validate
by touching
ESCAPE
in the main screen).
Indicator light display
1) At initialization, the display is amber when downloading infor-
mation from the base.
2) When ready the RTD displays a plain green light.
When printing, the light turns amber.
The green is blinking if multilabelling.
3) The indicator light turns to red when:
- You have reach the end of roll;
-The cover is open;
-There is no paper;
- RTD non operational.
10.5 Maintenance
Periodic cleaning
- Switch off the RTD.
- Clean the printhead with the cleaning pen, when loading a new roll.
Only use approved cleaning pen (provided with the RTD) to clean
the printhead. Order a new one when it is getting dirty or dry.
DO NOT CLEAN THE BLACK PRINT ROLLER.
