MP60, MP60DP
CAN INTERFACE DESCRIPTION
58
ValuesAttr.FormatNameSub
index
Index
(hex)
2122 1 Physical unit visible
string
rw 4 char
2131 1 Measuring range unsigned16 rw 533: 1 MHz
534: 100 kHz
531: 20 kHz
535: 10 kHz
536: 1 kHz
1646: 5 MImp
1647: 1 GImp
2132 1 F2 Enable (2nd fre
quency response)
unsigned16 rw 1: On
0: Off
2133 1 Zero index unsigned16 rw 1: On
0: Off
2134 1 Frequency
quadrupling
unsigned16 rw 1: On
0: Off
2135 1 Direction of rotation unsigned16 rw 1: On
0: Off
2136 1 Trigger level float rw Value in range "5 V
(keyboard: 250 mV
steps)
2137 1 Glitch filter unsigned16 rw 1: On
0: Off
2138 1 Shunt unsigned16 rw 1: On
0: Off
2139 1 Enable transducer
error input
unsigned16 rw 1: On
0: Off
2140 1 Transducer zero kHz integer32 rw Value in kHz
2141 1 Transducer zero
phys. unit
integer32 rw Value e.g. in kN
2142 1 Transducer
sensitivity kHz
integer32 rw Value in kHz
2143 1 Transducer
sensitivity phys. unit
integer32 rw Value e.g. in kN
