71
MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION
(MP60DP ONLY)
Parameter name Possible
values
Default Meaning
Diagnosis Disabled
Enabled
Enabled External diagnosis enabled
Data format 16-bit integer
32-bit integer
Floating point
16-bit integer Defines the coding format for
measured values
Zeroing control bit Disabled
Enabled
Disabled Enables functionality for control
via output control word
Taring control bit Disabled
Enabled
Disabled Enables functionality for control
via output control word
Clear maximum
control bit
Disabled
Enabled
Disabled Enables functionality for control
via output control word
Clear minimum
control bit
Disabled
Enabled
Disabled Enables functionality for control
via output control word
Hold maximum
control bit
Disabled
Enabled
Disabled Enables functionality for control
via output control word
Hold minimum
control bit
Disabled
Enabled
Disabled Enables functionality for control
via output control word
Parameter set
control bit
Disabled
Enabled
Disabled Enables functionality for control
via output control word
Tab. 10.1 Meanings of the parameters
The set data format applies to all the measured values exchanged during cyclic data
communication. The decimal place specification for the 16-bit and 32-bit integer formats
is taken from the module setting (display, CAN bus), e.g. when 3 decimal places are
specified, 2.0 mm is transferred as the integer value 2000. The choice of data format
also affects the length of the input data (16-bit integer = 1 word per analog value; 32-bit
integer = 2 words per analog value).
Targeted enabling of the required control bits in the control word offers the possibility to
protect all unneeded functions against an unintentional activation in the event of an error.
Otherwise a set zero point might be lost for example.
If you are using older parameterization tools, the parameter values must be converted to
decimal or hexadecimal values:
