83
MP60, MP60DP
ERROR MESSAGES/OPERATING STATE (LED)
MP60DP operating state and LED signaling
During measurement, press
+ −
to view the status messages (e.g. mV; V; Outp, Inpt;
error messages).
After the "ERROR" status message, the display shows the status of the Profibus DP
connection. One of the following status messages is displayed each time:
S BD_SEAR (baud rate search)
S WT_PARM (waiting for parameter)
S WT_CONF (waiting for configuration)
S DATA_EX (cyclic data traffic)
S ERROR (bus error)
The LEDs indicate the operating states (ready for measurement, overflow, etc.) of the
MP60DP. But (as in the MP60) the PROFIBUS state is indicated, not the CAN state.
Operating state:
LED color State Meaning
Profibus state
Green Steady light DATA_EX state
Yellow Steady light BD_SEAR, WT_PARM, WT_CONF states
Red Steady light ERROR state
The display of the other operating states corresponds to those of the MP60.
