MP60, MP60DP
ERROR MESSAGES/OPERATING STATE (LED)
82
Information
The MP60 can indicate transducer errors generated by the torque sensor. But to do this,
the error signal from the torque sensor must be connected across pin 7 of the transducer
plugs (15-pin sub-D plugs).
The "transducer error" function in the MP60 must also be activated.
Operating state and LED signaling
LED
color
State Meaning
Measuring mode Bus mode
Green Steady
light
Ready for measurement CAN Operational (PDO transfer
possible)
Green Flashing Data being transferred over the
interface
-
Yellow Steady
light
Ready for measurement CAN bus PreOperational
(PDO transfer not possible)
LED
color
State
Meaning
Remedy
Measuring mode Bus mode
Red Flashing Measured value
overflow
LCD error
CAN Transmit error
Adapt
measuring
range
Restart
Red Steady
light
Initialization phase:
Not (yet) ready for
measurement,
calibration error
CAN bus not ready to
communicate
(bus OFF)
Wait
Initial calibration error Send the PME
to the manufac
turer (HBM)
