81
MP60, MP60DP
ERROR MESSAGES/OPERATING STATE (LED)
The current errors are displayed continuously for each channel (see also page 30). Keep
pressing
+
until you get to the "ERROR" display mode.
Error message Cause Remedy
Counter
(Cntr Ovfl)
Maximum number of count
pulses exceeded
Zero
Input
(Inpt Ovfl)
Input frequency too high Adapt measuring range
AnlgOutp
(AnlgOvfl)
Analog output overflow Check display value/analog output
assignment
PkValMin
(PkMinOvf)
Minimum peak value overflow 1. Use external remote control to
clear peak value or
2. In PEAKVAL group, "ClearPkV"
Yes
PkValMax
(PkMaxOvf)
Maximum peak value
overflow
1. Use external remote control to
clear peak value or
2. In PEAKVAL group, "ClearPkV"
Yes
Net
(Net+Ovf;
Net-Ovf)
Net value overflow
1)
Reduce display by one decimal place
Gross
(Grs+Ovf;
Grs-Ovf)
Gross value overflow
1)
Reduce display by one decimal place
Transducr Transducer error signal
(Low active)
See transducer operating manual
Scaling
2)
(Scal.Err)
Input characteristic too steep Change input characteristic
AnlgScal
(AScalErr)
Input or output characteristic
too steep
Change input or output
characteristic
(InitCalErr) No valid initial calibration
values
Restart, send the PME to the
manufacturer (HBM)
CAN Tx PDOs are not accepted on the
bus
Check CAN bus configuration
1)
±1000000 is outputted on the CAN bus
2)
See page 40
