HDG Compact 25 - Page 114

6 Using the heating system – Structure of the menus
114
i-21 District heating 1
Dist.h. Temp. 65°C
Dist.h. pump Off
• District heating information
Transfer temperature of district heating
Status of district heating pump
i-22 Oilburn. 1
Oil burn. temp 20?
Oil burn.enabl Off
• Information on oil-fired boiler
Temperature of oil-fired boiler
Status of oil-fired boiler
i-25 Tilting grate
Off ES0
Time 0/0 s
Start in
04:00:00
• Information on grate
Limit switch status indicator ON/OFF
Tipping motion elapsed time
Next emptying in ... hours
i-26 Cleaning
Wait
Cycles 5/0
Start in 04:00:00
• Cleaning of heat exchanger surfaces
Operating status display
Number of cleaning cycles set/actual
Next cleaning in ... hours
i-27 Operating hours
Boiler 0h
Feeding system 0h
Dosage 0h
• Operating hours information
Boiler running time during heat production
Stoker auger running time
Running time of dosing unit
i-28 Operating hours
Times emptied 0a
Cleaning 0a
• Operating hours information
Number of grate emptyings
Running time of cleaning program
i-29 Digital values
IN: ----------------
Bit:0123456789abcdef
OUT:-*-**-----------
• Signal status of central unit
Status of digital inputs
Bit significance
Status of digital outputs
i-30 Digital values
IN: ----------------
Bit:0123456789abcdef
OUT: ---------------
• Signal status of transport module
Status of digital inputs
Bit significance
Status of digital outputs
i-31 Motor currents
Feeding system
0.000A
Dosing 0.000A
Delivery 0.000A
• Information on the motor currents
i-32 Buffer house 1
Temp. top 77?
Temp. bottom 65°C
Pump off
• District heating pump 1
Current temperature at top of accumulator
Current temperature at bottom of accumulator
Status of district heating pump
No. Display Description
Table 6/2 - Information level
