3 - IGNITION
No. Display Description
3-01 Ignition
Self-igniting temp./
Enabling temp. Autom.
( 150) 150°
• Self-igniting temperature
If the combustion chamber temp. is greater than the self-
igniting temp., the boiler starts without first filling and
igniting. (50 - 500 °C)
3-02 Ignition
Fill comb. chamber
Duration
( 5) 5m
• Filling time for combustion chamber
The combustion chamber is filled for ignition during this
time. The fuel should contact the ignition pipe within this
time. (0 - 15 min)
3-03 Ignition
Fill comb. chamber
Fuel quantity
( 20) 20%
• Fuel quantity for combustion chamber filling
Setting option for the fuel quantity which is carried in
during the first filling (cycle frequency of the feeding
augers). (0 - 100 %)
3-04 Ignition
Fill comb. chamber
Primary air
( 20) 20%
• Primary air volume for combustion chamber filling
Setting option for the primary air quantity which is sup-
plied during the first filling.
(0 - 100 %)
3-05 Ignition
Fill comb. chamber
Secondary air
( 10) 10%
• Secondary air volume for combustion chamber filling
Setting option for the secondary air quantity which is sup-
plied during the first filling.
(0 - 100 %)
3-06 Ignition
Fill comb. chamber
Flue gas fan
( 20) 20%
• Flue gas fan setting for first filling
Setting option for the speed of the flue gas fan in the flue
for the first filling.
(0 - 100 %)
3-07 Ignition
Ignition
Duration
( 6) 6m
• Ignition time
The ignition fan runs until the preset time has elapsed.
(0 - 10 min)
3-08 Ignition
Ignition
Primary air
( 20) 20%
• Primary air for ignition
Setting option for the primary air volume supplied during
ignition.
(0 - 100 %)
3-09 Ignition
Ignition
Secondary air
( 0) 0%
• Secondary air for ignition
Setting option for the secondary air volume supplied
during ignition.
(0 - 100 %)
3-10 Ignition
Ignition
Flue gas fan
( 20) 20%
• Flue gas fan setting for ignition
Setting option for the speed of a flue gas fan for ignition.
(0 - 100 %)
Table 6/5 - System level / 3 - Ignition
