3-11 Ignition
Ignition
Add fan
( 1) 1m
• Fan connection for ignition
Connection of primary and secondary air fans to the igni-
tion fan after this preset time has elapsed (= fire kindling).
(0 - 10 m)
3-13 Ignition
Pre-ventilation
Duration
( 30) 30s
• Duration of pre-ventilation function
Setting option for the pre-ventilation time
(0 - 60 s)
3-14 Ignition
Pre-ventilation
Primary air
( 30) 30%
• Primary air for pre-ventilation
Setting option for the primary air volume supplied during
pre-ventilation.
(0 - 100 %)
3-15 Ignition
Pre-ventilation
Secondary air
( 10) 10%
• Secondary air for pre-ventilation
Setting option for the secondary air volume supplied
during pre-ventilation.
(0 - 100 %)
3-16 Ignition
Pre-ventilation
Flue gas fan
( 20) 20%
• Flue gas fan setting for pre-ventilation
Setting option for the speed of a flue gas fan for pre-ven-
tilation.
(0 - 100 %)
3-17 Ignition
Heating-up
Duration
( 5) 5m
• Heating-up time
Setting option for the heating-up phase duration.
(1 - 30 min)
3-18 Ignition
Start heating up
Fuel quantity
( 6) 6%
• Fuel quantity for start of heating-up phase
This preset value determines the fuel quantity with which
the heating-up phase begins.
(0 - 100 %)
3-19 Ignition
End heating up
Fuel quantity
( 20) 20%
• Fuel quantity for ending the heating-up phase
The fuel quantity increases up to this preset value during
the heating-up phase.
(0 - 100 %)
3-20 Ignition
Heating-up
Primary air
( 40) 40%
• Primary air for heating-up phase
Setting option for the primary air volume supplied during
the heating-up phase.
(0 - 100 %)
3-21 Ignition
Heating-up
Secondary air
( 10) 10%
• Secondary air for heating-up phase
Setting option for the secondary air volume supplied
during the heating-up phase.
(0 - 100 %)
No. Display Description
Table 6/5 - System level / 3 - Ignition
